Air Conditioner and Heater Plumbing for 2012 Jeep Patriot
No.
Part # / Description / Price
Price
1
A/c Suction Line
Mopar
Mopar Notes: Engines: 2.0L I4 DOHC 16V DUAL VVT ENGINE. 2.4L I4 DOHC 16V DUAL VVT ENGINE. Transmissions: 5-SPEED MANUAL T355 TRANSMISSION. CONT.VAR. W/OFF-RD CRAWL RATIO TRANS. CONTINUOUSLY VARIABLE TRANSAXLE II.
Description: A/C SUCTION
2
Slim Line Seal Mopar
Mopar Notes: Engines: 2.2L I4 SINGLE TD OM651 ENGINE. Transmissions: 5-SPEED MANUAL T355 TRANSMISSION. 6-SPEED MANUAL AISIN BG6 TRANS. CONT.VAR. W/OFF-RD CRAWL RATIO TRANS. CONTINUOUSLY VARIABLE TRANSAXLE II.
Description: 5/8". Serviced with Expansion Valve
Not For Sale
Not For Sale
3
A/c Discharge Line Mopar
Mopar Notes: Transmissions: 5-SPEED MANUAL T355 TRANSMISSION. CONTINUOUSLY VARIABLE TRANSAXLE II.
Description: On Or After 06/28/2010
4
Sealing Washer Mopar
Mopar Notes: Transmissions: 5-SPEED MANUAL T355 TRANSMISSION. 6-SPEED MANUAL AISIN BG6 TRANS. CONT.VAR. W/OFF-RD CRAWL RATIO TRANS. CONTINUOUSLY VARIABLE TRANSAXLE II.
Description: Condenser or Compressor End
MSRP $32.25
$23.41
MSRP $32.25
$23.41
5
A/c Pressure Transducer Valve Mopar
Mopar Notes: Transmissions: 5-SPEED MANUAL T355 TRANSMISSION. 6-SPEED MANUAL AISIN BG6 TRANS. CONT.VAR. W/OFF-RD CRAWL RATIO TRANS. CONTINUOUSLY VARIABLE TRANSAXLE II.
Description: Includes: O-Ring. On Or After 06/28/2010
MSRP $133.00
$91.14
MSRP $133.00
$91.14
6
A/c Line O Ring Mopar
Mopar Notes: Transmissions: 5-SPEED MANUAL T355 TRANSMISSION. 6-SPEED MANUAL AISIN BG6 TRANS. CONT.VAR. W/OFF-RD CRAWL RATIO TRANS. CONTINUOUSLY VARIABLE TRANSAXLE II.
Description: For Transducer Valve
MSRP $24.55
$17.61
MSRP $24.55
$17.61
7
A/c Suction And Liquid Line Mopar
Mopar Notes: Transmissions: 5-SPEED MANUAL T355 TRANSMISSION. CONT.VAR. W/OFF-RD CRAWL RATIO TRANS.
Description: After 09/12/11
8
A/c Line Seal Mopar
Mopar Notes: Engines: 2.2L I4 SINGLE TD OM651 ENGINE. Transmissions: 5-SPEED MANUAL T355 TRANSMISSION. 6-SPEED MANUAL AISIN BG6 TRANS. CONT.VAR. W/OFF-RD CRAWL RATIO TRANS. CONTINUOUSLY VARIABLE TRANSAXLE II.
Description: Receiver Drier
MSRP $33.55
$24.14
MSRP $33.55
$24.14
10
Receiver Drier Mopar
Mopar Notes: Transmissions: 5-SPEED MANUAL T355 TRANSMISSION.
Description: Includes Tube On Bottom Of Drier
13
Air Conditioning Condenser Mopar
Mopar Description: NOTE:25 pc min Qty Mix and Match Pallet Program only, Use mopar.com to order, Magneti-Marelli Parts tab
13
Air Conditioning Condenser Mopar
Mopar Notes: Transmissions: 5-SPEED MANUAL T355 TRANSMISSION.
Description: NOTE:25 pc min Qty Mix and Match Pallet Program only, Use mopar.com to order, Magneti-Marelli Parts tab. Manual Transmission [DD7,DEF]
14
Hex Flange Nut Mopar
Mopar Notes: Engines: 2.0L I4 DOHC 16V DUAL VVT ENGINE. 2.0L I4 DOHC 16V E22 VVT ENGINE. 2.0L I4 PZEV 16V DUAL VVT ENGINE. 2.2L I4 SINGLE TD OM651 ENGINE. 2.4L I4 DOHC 16V DUAL VVT ENGINE. 2.4L I4 PZEV 16V DUAL VVT ENGINE. Transmissions: 5-SPEED MANUAL T355 TRANSMISSION. 6-SPEED MANUAL AISIN BG6 TRANS. CONT.VAR. W/OFF-RD CRAWL RATIO TRANS. CONTINUOUSLY VARIABLE TRANSAXLE II.
Description: M8x1.25x8.0. Park Brake Lever to Park Brake Sled
Not For Sale
Not For Sale
14
Hex Flange Nut Mopar
Mopar Notes: Engines: 2.0L I4 DOHC 16V DUAL VVT ENGINE. 2.0L I4 DOHC 16V E22 VVT ENGINE. 2.2L I4 SINGLE TD OM651 ENGINE. 2.4L I4 DOHC 16V DUAL VVT ENGINE. Transmissions: 5-SPEED MANUAL T355 TRANSMISSION. 6-SPEED MANUAL AISIN BG6 TRANS. CONT.VAR. W/OFF-RD CRAWL RATIO TRANS. CONTINUOUSLY VARIABLE TRANSAXLE II.
Description: M8x1.25x8.0. Park Brake Lever to Park Brake Sled
Not For Sale
Not For Sale
15
Hex Flange Head Screw Mopar
Mopar Notes: Engines: 2.2L I4 SINGLE TD OM651 ENGINE. Transmissions: 6-SPEED MANUAL AISIN BG6 TRANS.
Description: M8x1.25x35
MSRP $5.05
$3.63
MSRP $5.05
$3.63
16
A/c Charge Valve Cap Mopar
Mopar Notes: Engines: 2.2L I4 SINGLE TD OM651 ENGINE. Transmissions: 5-SPEED MANUAL T355 TRANSMISSION. CONT.VAR. W/OFF-RD CRAWL RATIO TRANS. CONTINUOUSLY VARIABLE TRANSAXLE II.
Description: High Side
16
A/c Charge Valve Cap Mopar
Mopar Notes: Engines: 2.2L I4 SINGLE TD OM651 ENGINE. Transmissions: 5-SPEED MANUAL T355 TRANSMISSION. CONT.VAR. W/OFF-RD CRAWL RATIO TRANS. CONTINUOUSLY VARIABLE TRANSAXLE II.
Description: Low side
No.
Part # / Description / Price
Price
1
A/c Suction Line Mopar
Mopar Notes: Engines: 2.0L I4 DOHC 16V DUAL VVT ENGINE. 2.4L I4 DOHC 16V DUAL VVT ENGINE. Transmissions: 5-SPEED MANUAL T355 TRANSMISSION. CONT.VAR. W/OFF-RD CRAWL RATIO TRANS. CONTINUOUSLY VARIABLE TRANSAXLE II.
Description: A/C SUCTION
2
Slim Line Seal Mopar
Mopar Notes: Engines: 2.2L I4 SINGLE TD OM651 ENGINE. Transmissions: 5-SPEED MANUAL T355 TRANSMISSION. 6-SPEED MANUAL AISIN BG6 TRANS. CONT.VAR. W/OFF-RD CRAWL RATIO TRANS. CONTINUOUSLY VARIABLE TRANSAXLE II.
Description: 5/8". Serviced with Expansion Valve
Not For Sale
Not For Sale
3
A/c Discharge Line Mopar
Mopar Notes: Transmissions: 5-SPEED MANUAL T355 TRANSMISSION. CONTINUOUSLY VARIABLE TRANSAXLE II.
Description: On Or After 06/28/2010
4
Sealing Washer Mopar
Mopar Notes: Transmissions: 5-SPEED MANUAL T355 TRANSMISSION. 6-SPEED MANUAL AISIN BG6 TRANS. CONT.VAR. W/OFF-RD CRAWL RATIO TRANS. CONTINUOUSLY VARIABLE TRANSAXLE II.
Description: Condenser or Compressor End
MSRP $32.25
$23.41
MSRP $32.25
$23.41
5
A/c Pressure Transducer Valve Mopar
Mopar Notes: Transmissions: 5-SPEED MANUAL T355 TRANSMISSION. 6-SPEED MANUAL AISIN BG6 TRANS. CONT.VAR. W/OFF-RD CRAWL RATIO TRANS. CONTINUOUSLY VARIABLE TRANSAXLE II.
Description: Includes: O-Ring. On Or After 06/28/2010
MSRP $133.00
$91.14
MSRP $133.00
$91.14
6
A/c Line O Ring Mopar
Mopar Notes: Transmissions: 5-SPEED MANUAL T355 TRANSMISSION. 6-SPEED MANUAL AISIN BG6 TRANS. CONT.VAR. W/OFF-RD CRAWL RATIO TRANS. CONTINUOUSLY VARIABLE TRANSAXLE II.
Description: For Transducer Valve
MSRP $24.55
$17.61
MSRP $24.55
$17.61
8
A/c Line Seal Mopar
Mopar Notes: Engines: 2.2L I4 SINGLE TD OM651 ENGINE. Transmissions: 5-SPEED MANUAL T355 TRANSMISSION. 6-SPEED MANUAL AISIN BG6 TRANS. CONT.VAR. W/OFF-RD CRAWL RATIO TRANS. CONTINUOUSLY VARIABLE TRANSAXLE II.
Description: Receiver Drier
MSRP $33.55
$24.14
MSRP $33.55
$24.14
11
Receiver Drier Mopar
Mopar Notes: Engines: 2.0L I4 DOHC 16V DUAL VVT ENGINE. 2.0L I4 PZEV 16V DUAL VVT ENGINE. 2.4L I4 DOHC 16V DUAL VVT ENGINE. 2.4L I4 PZEV 16V DUAL VVT ENGINE.
Description: This Drier Does Not Have A Tube On The Bottom
MSRP $333.00
$218.67
MSRP $333.00
$218.67
12
Receiver Drier O Ring Mopar
Mopar Notes: Engines: 2.0L I4 DOHC 16V DUAL VVT ENGINE. 2.0L I4 PZEV 16V DUAL VVT ENGINE. 2.4L I4 DOHC 16V DUAL VVT ENGINE. 2.4L I4 PZEV 16V DUAL VVT ENGINE.
Description: Drier to Condenser
MSRP $9.45
$5.71
MSRP $9.45
$5.71
13
Condenser And Trans Cooler Cooler Mopar
Mopar Notes: Engines: 2.0L I4 DOHC 16V DUAL VVT ENGINE. 2.0L I4 PZEV 16V DUAL VVT ENGINE. 2.4L I4 DOHC 16V DUAL VVT ENGINE. 2.4L I4 PZEV 16V DUAL VVT ENGINE.
Description: NOTE:25 pc min Qty Mix and Match Pallet Program only, Use mopar.com to order, Magneti-Marelli Parts tab
14
Hex Flange Nut Mopar
Mopar Notes: Engines: 2.0L I4 DOHC 16V DUAL VVT ENGINE. 2.0L I4 DOHC 16V E22 VVT ENGINE. 2.0L I4 PZEV 16V DUAL VVT ENGINE. 2.2L I4 SINGLE TD OM651 ENGINE. 2.4L I4 DOHC 16V DUAL VVT ENGINE. 2.4L I4 PZEV 16V DUAL VVT ENGINE. Transmissions: 5-SPEED MANUAL T355 TRANSMISSION. 6-SPEED MANUAL AISIN BG6 TRANS. CONT.VAR. W/OFF-RD CRAWL RATIO TRANS. CONTINUOUSLY VARIABLE TRANSAXLE II.
Description: M8x1.25x8.0. Park Brake Lever to Park Brake Sled
Not For Sale
Not For Sale
14
Hex Flange Nut Mopar
Mopar Notes: Engines: 2.0L I4 DOHC 16V DUAL VVT ENGINE. 2.0L I4 DOHC 16V E22 VVT ENGINE. 2.2L I4 SINGLE TD OM651 ENGINE. 2.4L I4 DOHC 16V DUAL VVT ENGINE. Transmissions: 5-SPEED MANUAL T355 TRANSMISSION. 6-SPEED MANUAL AISIN BG6 TRANS. CONT.VAR. W/OFF-RD CRAWL RATIO TRANS. CONTINUOUSLY VARIABLE TRANSAXLE II.
Description: M8x1.25x8.0. Park Brake Lever to Park Brake Sled
Not For Sale
Not For Sale
15
Hex Flange Head Screw Mopar
Mopar Notes: Engines: 2.2L I4 SINGLE TD OM651 ENGINE. Transmissions: 6-SPEED MANUAL AISIN BG6 TRANS.
Description: M8x1.25x35
MSRP $5.05
$3.63
MSRP $5.05
$3.63
16
Hex Head Bolt And Washer, Mounting Mopar
Mopar Notes: Engines: 2.2L I4 SINGLE TD OM651 ENGINE.
Description: M8X1.25X25.00. Engine Oil Indicator Tube To Cylinder Block
MSRP $11.90
$8.47
MSRP $11.90
$8.47
17
A/c Charge Valve Cap Mopar
Mopar Notes: Engines: 2.2L I4 SINGLE TD OM651 ENGINE. Transmissions: 5-SPEED MANUAL T355 TRANSMISSION. CONT.VAR. W/OFF-RD CRAWL RATIO TRANS. CONTINUOUSLY VARIABLE TRANSAXLE II.
Description: High Side
17
A/c Charge Valve Cap Mopar
Mopar Notes: Engines: 2.2L I4 SINGLE TD OM651 ENGINE. Transmissions: 5-SPEED MANUAL T355 TRANSMISSION. CONT.VAR. W/OFF-RD CRAWL RATIO TRANS. CONTINUOUSLY VARIABLE TRANSAXLE II.
Description: Low side
No.
Part # / Description / Price
Price
2
Sealing Washer Mopar
Mopar Notes: Transmissions: 5-SPEED MANUAL T355 TRANSMISSION. 6-SPEED MANUAL AISIN BG6 TRANS. CONT.VAR. W/OFF-RD CRAWL RATIO TRANS. CONTINUOUSLY VARIABLE TRANSAXLE II.
Description: Condenser or Compressor End
MSRP $32.25
$23.41
MSRP $32.25
$23.41
3
A/c Discharge Line Mopar
Mopar Notes: Transmissions: 6-SPEED MANUAL AISIN BG6 TRANS.
Description: A/C DISCHARGE
4
Slim Line Seal Mopar
Mopar Notes: Engines: 2.2L I4 SINGLE TD OM651 ENGINE. Transmissions: 5-SPEED MANUAL T355 TRANSMISSION. 6-SPEED MANUAL AISIN BG6 TRANS. CONT.VAR. W/OFF-RD CRAWL RATIO TRANS. CONTINUOUSLY VARIABLE TRANSAXLE II.
Description: 5/8". Serviced with Expansion Valve
Not For Sale
Not For Sale
5
A/c Pressure Transducer Valve Mopar
Mopar Notes: Transmissions: 5-SPEED MANUAL T355 TRANSMISSION. 6-SPEED MANUAL AISIN BG6 TRANS. CONT.VAR. W/OFF-RD CRAWL RATIO TRANS. CONTINUOUSLY VARIABLE TRANSAXLE II.
Description: Includes: O-Ring. On Or After 06/28/2010
MSRP $133.00
$91.14
MSRP $133.00
$91.14
6
A/c Line O Ring Mopar
Mopar Notes: Transmissions: 5-SPEED MANUAL T355 TRANSMISSION. 6-SPEED MANUAL AISIN BG6 TRANS. CONT.VAR. W/OFF-RD CRAWL RATIO TRANS. CONTINUOUSLY VARIABLE TRANSAXLE II.
Description: For Transducer Valve
MSRP $24.55
$17.61
MSRP $24.55
$17.61
8
A/c Line Seal Mopar
Mopar Notes: Engines: 2.2L I4 SINGLE TD OM651 ENGINE. Transmissions: 5-SPEED MANUAL T355 TRANSMISSION. 6-SPEED MANUAL AISIN BG6 TRANS. CONT.VAR. W/OFF-RD CRAWL RATIO TRANS. CONTINUOUSLY VARIABLE TRANSAXLE II.
Description: Receiver Drier
MSRP $33.55
$24.14
MSRP $33.55
$24.14
10
Receiver Drier Mopar
Mopar Notes: Transmissions: 6-SPEED MANUAL AISIN BG6 TRANS.
Description: After 10/31/11
14
Hex Flange Nut Mopar
Mopar Notes: Engines: 2.0L I4 DOHC 16V DUAL VVT ENGINE. 2.0L I4 DOHC 16V E22 VVT ENGINE. 2.0L I4 PZEV 16V DUAL VVT ENGINE. 2.2L I4 SINGLE TD OM651 ENGINE. 2.4L I4 DOHC 16V DUAL VVT ENGINE. 2.4L I4 PZEV 16V DUAL VVT ENGINE. Transmissions: 5-SPEED MANUAL T355 TRANSMISSION. 6-SPEED MANUAL AISIN BG6 TRANS. CONT.VAR. W/OFF-RD CRAWL RATIO TRANS. CONTINUOUSLY VARIABLE TRANSAXLE II.
Description: M8x1.25x8.0. Park Brake Lever to Park Brake Sled
Not For Sale
Not For Sale
14
Hex Flange Nut Mopar
Mopar Notes: Engines: 2.0L I4 DOHC 16V DUAL VVT ENGINE. 2.0L I4 DOHC 16V E22 VVT ENGINE. 2.2L I4 SINGLE TD OM651 ENGINE. 2.4L I4 DOHC 16V DUAL VVT ENGINE. Transmissions: 5-SPEED MANUAL T355 TRANSMISSION. 6-SPEED MANUAL AISIN BG6 TRANS. CONT.VAR. W/OFF-RD CRAWL RATIO TRANS. CONTINUOUSLY VARIABLE TRANSAXLE II.
Description: M8x1.25x8.0. Park Brake Lever to Park Brake Sled
Not For Sale
Not For Sale
15
Hex Flange Head Screw Mopar
Mopar Notes: Engines: 2.2L I4 SINGLE TD OM651 ENGINE. Transmissions: 6-SPEED MANUAL AISIN BG6 TRANS.
Description: M8x1.25x35
MSRP $5.05
$3.63
MSRP $5.05
$3.63
16
A/c Charge Valve Cap Mopar
Mopar Notes: Engines: 2.2L I4 SINGLE TD OM651 ENGINE. Transmissions: 5-SPEED MANUAL T355 TRANSMISSION. CONT.VAR. W/OFF-RD CRAWL RATIO TRANS. CONTINUOUSLY VARIABLE TRANSAXLE II.
Description: High Side
No.
Part # / Description / Price
Price
2
Heater Supply Hose Mopar
Mopar Notes: Engines: 2.0L I4 DOHC 16V DUAL VVT ENGINE. 2.0L I4 DOHC 16V E22 VVT ENGINE. 2.4L I4 DOHC 16V DUAL VVT ENGINE.
Description: Includes: Clamps
2
Heater Core Hose Mopar
Mopar Notes: Engines: 2.0L I4 DOHC 16V DUAL VVT ENGINE. 2.0L I4 DOHC 16V E22 VVT ENGINE. 2.4L I4 DOHC 16V DUAL VVT ENGINE.
Description: Supply And Return. Includes: Clamps
MSRP $64.70
$44.45
MSRP $64.70
$44.45
3
Heater Return Hose Mopar
Mopar Notes: Engines: 2.0L I4 DOHC 16V DUAL VVT ENGINE. 2.0L I4 DOHC 16V E22 VVT ENGINE. 2.4L I4 DOHC 16V DUAL VVT ENGINE.
Description: Includes: Clamps
