Engine Mounting for 2010 Chrysler Town & Country
No.
Part # / Description / Price
Price
1
Hex Head Bolt And Coned Washer, Mounting
Mopar
Mopar Notes: Engines: 2.8L I4 TURBO DIESEL ENGINE. 3.3L V6 OHV ENGINE. 3.8L V6 OHV ENGINE. 4.0L V6 SOHC ENGINE. Transmissions: 6-SPEED AUTOMATIC 62TE TRANSMISSION.
Description: M10X1.5X65.00. Front Engine Support To Cradle Middle Location [M10x1.5x65.0]
MSRP $7.45
$5.26
MSRP $7.45
$5.26
2
Hex Flange Head Bolt, Mounting Mopar
Mopar Notes: Engines: 2.8L I4 TURBO DIESEL ENGINE. 3.3L V6 OHV ENGINE. 3.8L V6 OHV ENGINE. 4.0L V6 SOHC ENGINE.
Description: M10x1.50x25.00. Heater Hose & Tube Return To Transaxle [M10x1.50x25.00]
MSRP $5.65
$3.99
MSRP $5.65
$3.99
3
Engine Support Mopar
Mopar Notes: Engines: 3.3L V6 OHV ENGINE. 3.8L V6 OHV ENGINE.
Description: ENGINE
MSRP $126.00
$85.22
MSRP $126.00
$85.22
4
Engine Mount Support, Front Mopar
Mopar Notes: Engines: 3.3L V6 OHV ENGINE. 3.8L V6 OHV ENGINE. 4.0L V6 SOHC ENGINE.
Description: Engine Mount
MSRP $266.00
$174.27
MSRP $266.00
$174.27
6
Hex Flange Head Bolt, Mounting Mopar
Mopar Notes: Engines: 3.3L V6 OHV ENGINE. 3.8L V6 OHV ENGINE. 4.0L V6 SOHC ENGINE.
Description: M8X1.25X25.00. Exhaust Manifold/Converter Assembly To Support Bracket
MSRP $4.30
$2.60
MSRP $4.30
$2.60
7
Engine Mount Isolator, Front Mopar
Mopar Description: [Thread-M12x1.5]. Engine Mount Left
MSRP $113.00
$77.17
MSRP $113.00
$77.17
8
Hex Flange Head Bolt, Mounting Mopar
Mopar Description: M10x1.50x50. Front Engine Mount To Engine Member Restraint Assembly [M10x1.50x50.00]
10
Hex Head Bolt, Mounting Mopar
Mopar Notes: Engines: 2.8L I4 TURBO DIESEL ENGINE. 3.3L V6 OHV ENGINE. 3.8L V6 OHV ENGINE. 4.0L V6 SOHC ENGINE.
Description: M12-1.75x60. Cylinder Block to Transmission
11
Hex Nut And Washer Mopar
Mopar Notes: Engines: 2.8L I4 TURBO DIESEL ENGINE. 3.3L V6 OHV ENGINE. 3.8L V6 OHV ENGINE. 4.0L V6 SOHC ENGINE.
Description: M10x1.5. Engine Mount To Engine Mount Bracket. Engine Mount To Engine Mount Bracket
12
Hex Flange Head Bolt Mopar
Mopar Notes: Engines: 2.8L I4 TURBO DIESEL ENGINE. 3.3L V6 OHV ENGINE. 3.8L V6 OHV ENGINE. 4.0L V6 SOHC ENGINE.
Description: M10x1.50x35.00. Isolator Assembly to Cradle
MSRP $3.70
$2.19
MSRP $3.70
$2.19
13
Hex Head Bolt And Washer, Mounting Mopar
Mopar Notes: Engines: 2.8L I4 TURBO DIESEL ENGINE. 3.3L V6 OHV ENGINE. 3.8L V6 OHV ENGINE. 4.0L V6 SOHC ENGINE.
Description: M10X1.50X105.00. Inner Cover To Left Cylinder Head
No.
Part # / Description / Price
Price
1
2
Transmission Support Mopar
Mopar Notes: Engines: 3.3L V6 OHV ENGINE. 3.8L V6 OHV ENGINE. 4.0L V6 SOHC ENGINE.
Description: Rear Engine Mount
MSRP $276.00
$180.93
MSRP $276.00
$180.93
3
Hex Head Bolt And Washer Mopar
Mopar Notes: Engines: 2.8L I4 TURBO DIESEL ENGINE. 3.3L V6 OHV ENGINE. 3.8L V6 OHV ENGINE. 4.0L V6 SOHC ENGINE. Transmissions: 4-SPEED AUTOMATIC VLP TRANSMISSION. 6-SPEED AUTOMATIC 62TE TRANSMISSION.
Description: M12X1.75X50.00. Transmission To Engine Block
MSRP $14.25
$10.35
MSRP $14.25
$10.35
4
Hex Head Bolt And Coned Washer, Mounting Mopar
Mopar Description: M10X1.50X130.00. Rear Engine Mount Through Bolt [M10x1.50x130.00]
MSRP $9.15
$6.53
MSRP $9.15
$6.53
5
Hex Flange Head Bolt, Mounting Mopar
Mopar Notes: Engines: 2.8L I4 TURBO DIESEL ENGINE. 3.3L V6 OHV ENGINE. 3.8L V6 OHV ENGINE. 4.0L V6 SOHC ENGINE.
Description: M10x1.50x25.00. Heater Hose & Tube Return To Transaxle [M10x1.50x25.00]
MSRP $5.65
$3.99
MSRP $5.65
$3.99
6
Hex Head Bolt, Mounting Mopar
Mopar Notes: Engines: 2.8L I4 TURBO DIESEL ENGINE. 3.8L V6 OHV ENGINE. 4.0L V6 SOHC ENGINE.
Description: M6x1.00x20.00. Heat Sheild To Engine Mount Bracket [M6x1.00x11.00]
MSRP $9.30
$6.72
MSRP $9.30
$6.72
7
Heat Shield Mopar
Mopar Notes: Engines: 2.8L I4 TURBO DIESEL ENGINE. 3.8L V6 OHV ENGINE. 4.0L V6 SOHC ENGINE.
Description: Rear Engine Mount And Half Shaft Boot
No.
Part # / Description / Price
Price
1
Transmission Mount Bracket, Left Side Mopar
Mopar Notes: Transmissions: 6-SPEED AUTOMATIC 62TE TRANSMISSION.
MSRP $115.00
$77.28
MSRP $115.00
$77.28
2
Transmission Support, Left Mopar
Mopar Notes: Engines: 3.3L V6 OHV ENGINE. 3.8L V6 OHV ENGINE. 4.0L V6 SOHC ENGINE.
Description: Engine Mount
MSRP $315.00
$189.72
MSRP $315.00
$189.72
3
Hex Flange Head Bolt, Mounting Mopar
Mopar Notes: Engines: 2.8L I4 TURBO DIESEL ENGINE. 3.3L V6 OHV ENGINE. 3.8L V6 OHV ENGINE. 4.0L V6 SOHC ENGINE. Transmissions: 6-SPEED AUTOMATIC 62TE TRANSMISSION.
Description: M10x1.50x40.00. Intermediate Shaft to Intermediate Bearing Bracket
MSRP $11.30
$8.17
MSRP $11.30
$8.17
4
Hex Flange Head Bolt, Mounting Mopar
Mopar Notes: Engines: 2.8L I4 TURBO DIESEL ENGINE. 3.3L V6 OHV ENGINE. 3.8L V6 OHV ENGINE. 4.0L V6 SOHC ENGINE.
Description: M10x1.50x60. Side Of Left Transmission Bracket To Transmission [M10x1.50x60.00]
MSRP $3.80
$2.72
MSRP $3.80
$2.72
5
Hex Head Bolt, Mounting Mopar
Mopar Description: M12X1.50X55.00. Left Engine Mount To Transmission Bracket [M12x1.50x55.00]
MSRP $6.20
$4.36
MSRP $6.20
$4.36
6
Hex Flange Head Bolt, Mounting Mopar
Mopar Notes: Engines: 2.8L I4 TURBO DIESEL ENGINE. 3.3L V6 OHV ENGINE. 3.8L V6 OHV ENGINE. 4.0L V6 SOHC ENGINE.
Description: M10x1.50x25.00. Heater Hose & Tube Return To Transaxle [M10x1.50x25.00]
MSRP $5.65
$3.99
MSRP $5.65
$3.99
No.
Part # / Description / Price
Price
1
Engine Mount Support Mopar
Mopar Notes: Engines: 4.0L V6 SOHC ENGINE.
Description: Rail To Engine
MSRP $192.00
$131.10
MSRP $192.00
$131.10
2
Hex Head Bolt And Washer Mopar
Mopar Notes: Engines: 2.8L I4 TURBO DIESEL ENGINE. 3.3L V6 OHV ENGINE. 3.8L V6 OHV ENGINE. 4.0L V6 SOHC ENGINE.
Description: M10x1.50x55.00. PTU Bracket to PTU
MSRP $3.70
$2.60
MSRP $3.70
$2.60
3
Hex Head Bolt And Washer, Mounting Mopar
Mopar Description: M10x1.50x40.00. Park Brake Cable Guide to Left Frame Rail
MSRP $3.90
$2.78
MSRP $3.90
$2.78
4
Ground Strap Mopar
Mopar Notes: Engines: 2.8L I4 TURBO DIESEL ENGINE. 3.3L V6 OHV ENGINE. 3.8L V6 OHV ENGINE. 3.XL Mid V6 Engine. 4.0L V6 SOHC ENGINE.
Description: engine mount to body
MSRP $16.30
$11.62
MSRP $16.30
$11.62
